Suzuki LS650F (1995) GEAR SHIFTING Diagram

#

Description
Price

1

FORK, GEAR SHIFTING NO.1

25211-24B00

Unavailable

2

FORK, GEAR SHIFTING NO.2

25221-24B00

Unavailable

3

SHAFT, GEAR SHIFTING FORK

25411-24B00

Unavailable

4

CAM, GEAR SHIFTING | Includes Item(s) 5

25310-24B02

Unavailable

5

PIN (4X13.8)

04221-04089

$1.10

6

GEAR, GEAR SHIFT CAM DRIVEN This part replaces 25322-31301.

25322-31310

$30.40

7

PAWL, GEAR SHIFT NO.1

25323-34201

$6.61

8

PAWL, GEAR SHIFT NO.2

25324-34201

$6.80

9

PIN

09261-05003

$1.69

10

SPRING

09440-04003

$1.48

11

LIFTER, PAWL

25331-38A00

Unavailable

12

GUIDE, CAM

25341-38A00

Unavailable

13

SCREW This part replaces 02122-06128.

02122-06127

$1.83

14

WASHER

09160-25059

$7.20

15

BOSS

25332-38A00

Unavailable

16

NUT This part replaces 09159-06017.

08319-31067

$2.01

17

BEARING (25X47X8) This part replaces 09262-25002.

09262-25006

$23.05

18

RETAINER This part replaces 24741-20A10.

24741-21A00

$2.80

19

SCREW This part replaces 02112-06128.

02112-06127

$1.83

20

STOPPER, CAM

25350-24B00

$16.77

21

SPRING

09448-17021

Unavailable

22

SUPPORT | <-25355-24B01

25356-12C00

$19.60

23

WASHER

08211-06141

$1.61

24

PLATE, STOPPER

25380-38A02

Unavailable

25

PIN

25312-38A00

$5.75

26

SHAFT, GEAR SHIFTING

25510-24B01

Unavailable

27

SPRING This part replaces 09444-26012.

09444-26013

$2.84

28

STOPPER, ARM This part replaces 25671-01000.

25671-01011

$4.09

29

OIL SEAL (12X22X9) This part replaces 09285-12002.

09285-12006

$5.70

30

LEVER ASSY,GEAR | MODEL G/J/K/L/M This part replaces 25600-24B01.

25600-24B04

$57.37

30

LEVER ASSY,GEAR | MODEL N/P; Includes Item(s) 31 This part replaces 25600-24B03.

25600-24B04

$57.37

31

COVER

25652-20C00

$4.98

32

WASHER (12.5X20X1)

09160-12011

$1.48

33

CIRCLIP This part replaces 08331-31126.

08331-3112A

$1.77

34

ARM,GEAR SHIFT This part replaces 25520-22A00.

25520-22A01

$47.47

35

ROD This part replaces 25525-49300.

25525-21E50

$9.36

36

NUT

09140-06011

$1.37

37

.NUT This part replaces 08310-11067.

08310-00067

$1.83

38

BOLT This part replaces 01107-06207.

01500-06207

$1.99

39

WASHER

08212-12201

$1.87

40

CIRCLIP This part replaces 08331-31126.

08331-3112A

$1.77

41

BODY, SWITCH | MODEL G

37720-24B00

Unavailable

41

BASE ASSY, NEUT SWITCH TERM | MODEL J/K/L/M/N/P This part replaces 37720-24B10.

37720-24B30

$78.27

42

SCREW This part replaces 02112-75166.

02112-7516A

$2.42

43

CONTACT, SWITCH

09209-05011

$2.02

44

SPRING

09440-04010

$1.52
