Sea-doo LRV, 5697, 2001 Rear Electrical Box Diagram

#

Description
Price

1

Mount Dart

293730040

$0.99

2

Tie-Rap 180 mm

414115200

$0.10

3

Electric Box Support Ass'y

278001426

Unavailable

4

Avdel Rivet 3/16"

293150037

$0.54

5

ELECTRIC BOX BASE - Call your local BRP dealership

278001425

Unavailable

6

ELECTRIC BOX COVER - Call your local BRP dealership

278001433

Unavailable

7

Ground Plate

278000732

Unavailable

8

Ground Wire

278001501

Unavailable

9

Hex. Elastic Stop Nut M6

232561600

$1.06

10

Socket Screw Button Head M6 X 10 | DS 650

250000436

$2.00

11

GASKET - Call your local BRP dealership

278001173

Unavailable

12

Starter Relay

278003012

$40.27

13

Hex. Flange Screw M6 X 10

210261040

$1.43

14

Ignition Coil (MAG)

278001416

Unavailable

15

COIL-IGNITION - Call your local BRP dealership

278001414

Unavailable

16

Hex. Forming Screw M6 X 20

207162060

$1.18

17

Hex. Screw M6 X 16

209561640

Unavailable

18

Grommet

278000682

Unavailable

19

Electric Wire Cap

278000100

Unavailable

20

Polyurethane Hose, 8 Mm 3000Mm Long

219704412

$31.31

21

SPARK PLUG CAP - Call your local BRP dealership

278000237

Unavailable

22

Was 293550004 Dielectric Grease, 150 g

219704453

$36.54

23

Ignition Coil Support

278001421

Unavailable

24

POSITIVE CABLE ASS'Y - Call your local BRP dealership | Includes 13 to 16

204470286

Unavailable

25

RED BOOT - Call your local BRP dealership

204470269

Unavailable

26

Electric Wire Cap

278000100

Unavailable

27

GROMMET - Call your local BRP dealership

278000098

Unavailable

28

REAR ELECTRIC BOX HARNESS - Call your local BRP dealership | Includes 22 - 31.

278001423

Unavailable

29

Male Terminal Housing, 6 Circuits

710001539

$17.88

30

Female Lock, 6 Circuits

278000735

$2.93

31

Male Terminal

278000631

$4.00

32

Male Connector, 2 Circuits

278001113

$14.52

33

Female Terminal

278001114

$2.93

34

Sealing Cap

293000052

$2.93

35

Male Terminal

278000230

$4.00

36

Ring Terminal

278000300

Unavailable

37

Insulated Sheath

278001008

$3.10

38

Fuse Harness (15 Amperes) | Includes 59 - 63.

278001212

Unavailable

39

Fuse, 15 Amperes

278000343

$3.12

40

Female Terminal | DS 650 X

278001009

$2.93

41

Insulated Sheath

278001007

$3.12

42

Ring Terminal

278000300

Unavailable

43

Tie Wrap 142 mm

293750002

$1.01

44

Gasket

293200030

Unavailable

45

STARTER RED CABLE - Call your local BRP dealership | Includes 44 to 47

278001437

Unavailable

46

Electric Wire Cap

278000100

Unavailable

47

GROMMET - Call your local BRP dealership

278000098

Unavailable

48

PROTECTION CAP - Call your local BRP dealership

278000020

Unavailable

49

SPLIT LOOM 3/8, METER - Call your local BRP dealership

204050326

Unavailable

50

Tie Wrap 94 mm | 4X4

293750001

$0.96

51

Flat Washer M6, Stainless

234062600

$0.73

52

Was 293550004 Dielectric Grease, 150 g

219704453

$36.54

53

Battery Support

278001430

Unavailable

54

Pop Rivet 3/16"

293150008

$0.46

55

Battery Lower Pad

278001234

Unavailable

56

Battery 19A | Includes 5 to 8

278001756

$144.75

57

Hex. Screw M6 X 16

207161644

$0.70

58

FLAT WASHER 6 MM - Call your local BRP dealership

211200018

Unavailable

59

Hex. Nut M6

232061414

$0.51

60

Retainer Strap

293850097

$10.63

61

Temperature Sensor

278002895

$36.54

62

Était/Was 293800038 Loctite 518, 50 ml

219704456

$48.48

63

NGK Spark Plug BR8ES This part replaces 278000609.

219703119

$4.63

64

Battery Ground Cable | Includes 51 - 52.

278001439

Unavailable

65

Not Available As Spare Part - Friction Washer

Unavailable

66

Hex. Screw M10 X 20, Scotch Grip

207302060

$3.78

67

Flat Washer 10 mm, Stainless

234001600

$1.04

68

Stainless Flat Washer M6

234061600

$0.28

69

Hex. Elastic Stop Nut M6

232561600

$1.06

70

SPARK PLUG WIRE - Call your local BRP dealership This part replaces 278001268.

278002198

Unavailable
