Kawasaki KX™450SR Front Fork(LNFNN) Diagram

#

Description
Price

11009

GASKET,FORK CYLINDER BOLT

11009-1592

$4.64

11065

CAP,CYLINDER COMP

11065-1333

$371.25

11065A

CAP,FORK

11065-1418

$429.17

39156

PAD,PROTECTION

39156-2799

$45.29

44008

PIPE-FORK OUTER

44008-0112

$784.27

44013

PIPE-FORK INNER,LH

44013-0396

$1,021.24

44013A

PIPE-FORK INNER,RH

44013-0397

$1,021.24

44023

CYLINDER-SET-FORK

44023-0168

$977.03

44026

SPRING-FRONT FORK

44026-0238

$122.78

44026A

SPRING-FRONT FORK,K=4.9N/MM

44026-0242

$104.97

44026B

SPRING-FRONT FORK,K=5.1N/MM

44026-0243

$104.97

44065

BUSHING-FRONT FORK

44065-0021

$17.39

44065A

BUSHING-FRONT FORK

44065-0022

$21.05

44075

DAMPER-SET-FORK

44075-0504

$5,189.68

46102

ROD,PISTON

46102-0654

$571.93

49116

VALVE-ASSY

49116-0721

$247.44

55020

GUARD,FORK,LH,EBONY

55020-2231-6C

$57.05

55020A

GUARD,FORK,RH,EBONY

55020-2232-6C

$49.34

92009

SCREW

92009-1884

$5.88

92026

SPACER

92026-0878

$72.49

92033

RING-SNAP

92033-0075

$4.10

92033A

RING-SNAP

92033-1329

$5.15

92049

SEAL-OIL

92049-0117

$24.59

92055

RING-O

92055-0106

$4.95

92055A

RING-O

92055-0116

$4.95

92055B

RING-O

92055-0117

$4.95

92055C

RING-O

92055-0730

$4.76

92055D

RING-O

92055-1156

$1.08

92055E

RING-O,2.8X6.6X1.9

92055-1441

$3.31

92093

SEAL,FORK OUTER TUBE

92093-1566

$16.80

92150

BOLT,5X16

92150-1802

$4.42

92152

COLLAR

92152-0824

$7.15

92153

BOLT,8X40

92153-0020

$4.24

92154

BOLT

92154-3776

$4.50

92173

CLAMP

92173-2196

$14.93

92200

WASHER

92200-1615

$11.71

92210

NUT

92210-0337

$21.54

99969

FORK CLAMP,XTRIG

99969-3880

$633.74
