Kawasaki KX™250F Kickstarter Mechanism Diagram

Description

Price

290

SCREW-SET-SOCKET,8X8

290CA0808

$2.34

480

CIRCLIP-TYPE-C,18MM

480J1800

$0.98

600

BALL-STEEL,1/4

600A0800

$0.59

13061

BOSS

13061-0147

Unavailable

13064

LEVER-ASSY-KICK

13064-0043

Unavailable

13066

SHAFT-KICK

13066-0004

$113.05

13070

GUIDE

13070-0011

$18.46

13078

RATCHET

13078-0013

$95.17

13206

GUIDE-KICK

13206-1062

$10.19

39115

SHAFT-IDLER,KICK

39115-0012

Unavailable

59051

GEAR-SPUR,KICK STARTER,26T

59051-0006

$130.58

59051A

GEAR-SPUR,KICK STARTER,28T

59051-0033

$130.19

92022

WASHER,17.3X25X0.5

92022-1614

$4.00

92022A

WASHER,10X22X3.2

92022-1944

$3.81

92022B

WASHER,18.3X22X0.5

92022-271

$4.18

92049

SEAL-OIL,KICK PEDAL

92049-1387

$4.67

92081

SPRING,KICK PEDAL

92081-020

$3.25

92145

SPRING,KICK STARTER

92145-0051

$24.10

92145A

SPRING

92145-0499

$14.25

92150

BOLT,8X25

92150-1858

$5.99

92151

BOLT,6X16

92151-1652

$1.34

92172

SCREW,6X33

92172-0248

$2.44

92200

WASHER,18.3X27.5X0.5

92200-0378

$1.81
