Find the part on the Rear Fender diagram for your 2017 Kawasaki KLX150BF, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2017 Kawasaki KLX150BF Rear Fender Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

132

1

$1.12

In stock

35019

FLAP,RR FENDER,FR

35019-0599

1
Out of stock

35019A

FLAP

35019-0613

1
Out of stock

35022

FENDER-COMP-REAR

35022-0102

1
Out of stock

35023B

FENDER-REAR,L.GREEN

35023-0402-290

1
Out of stock

35023C

FENDER-REAR,EBONY

35023-0402-6C

1
Out of stock

35034

REINFORCE

35034-0595

1
Out of stock

92009

SCREW,6X14

92009-3845

1
Out of stock

92075

DAMPER

92075-1629

1
Out of stock

92152

COLLAR

92152-0597

1
Out of stock

92152A

COLLAR,6.5X10X10.4

92152-1688

1
Out of stock

92152B

COLLAR,8.8X16X4

92152-1731

1
Out of stock

92152C

COLLAR,8.8X16X4

92152-2185

1
Out of stock

92154

BOLT,FLANGED-SMALL,6X16

92154-1183

1
Out of stock

92154A

BOLT,FLANGED,6X20

92154-1219

1
Out of stock

92161

DAMPER,15X35X10

92161-1559

1

$3.66

In stock
