Kawasaki KLR™650 Chassis Electrical Equipment Diagram

Description

Price

130

BOLT-FLANGED,6X10

130BB0610

$1.77

703

TUBE-RUBBER,8X12X580

703A08580

$19.49

11054

BRACKET,FUSE CASE

11054-0717

$10.93

13091

HOLDER,BATTERY COVER

13091-1484

$14.38

14024

COVER,BATTERY

14024-1375

$30.14

26006

FUSE,MINI BLADE,15A,BLUE

26006-0001

$5.34

26011

WIRE-LEAD,BATTERY(-)

26011-0116

$38.57

26011B

WIRE-LEAD,BATTERY(+)

26011-0175

$38.57

26012

BATTERY,FB14L-A2,12V 14AH

26012-0023

$115.04

26031

HARNESS,MAIN

26031-0604

$576.60

27002

RELAY-ASSY

27002-1088

$37.25

27002A

RELAY-ASSY,TURN SIGNAL

27002-1101

$73.74

27003

HORN

27003-0049

$84.92

49018

DIODE

49018-1052

Unavailable

92037

CLAMP,SPEED,L=58

92037-1163

$4.93

92037A

CLAMP,SPEED,L=80.5

92037-1903

$5.99

92072

BAND,L=202

92072-1195

$1.16

92072A

BAND,L=365

92072-1197

$7.71

92171

CLAMP,WIRING HARNESS,L=60

92171-1425

$1.36

92171A

CLAMP

92171-1597

$9.37

92172

SCREW,6X10

92172-0005

$1.73
