Kawasaki KDX200 OPTIONAL PARTS (KDX200-A2/A3) Diagram

Description

Price

25005

ODOMETER,MILE

25005-1061

$239.90

25008

BRACKET-METER

25008-1106

$18.05

41060

GEAR-METER SCREW

41059-027

Unavailable

41060A

GEAR-METER SCREW,8T

41060-015

Unavailable

41064

RECEIVER-SPEEDOMETER

41064-015

Unavailable

41078

CASE-ASSY-METER GEAR

41078-011

Unavailable

54001

CABLE,SPEEDOMETER

54001-4001

Unavailable

92009

SCREW,2X6

92009-1159

$2.15

92015

NUT,FLANGED,6MM

92015-1078

Unavailable

92015A

NUT-CAP

322C0500

Unavailable

92022

WASHER,5.2X16X1.2

25009-004

$3.03

92022A

WASHER,5.1X9X0.4

41063-001

$4.17

92022B

WASHER,24.5X32X0.8

41065-005

Unavailable

92027

COLLAR,L=13.1

92027-251

Unavailable

92028

BUSHING,SPEEDOMETER CABLE

41062-005

$18.66

92037

CLAMP,CABLE

92037-1481

$47.29

92043

PIN,SPRING

41082-001

$3.53

92075

DAMPER,METER

92075-1209

Unavailable

92075A

DAMPER,HEAD LAMP BRAC

92075-138

$2.41

92077

KNOB,METER TRIP

92077-1013

Unavailable

130

BOLT-FLANGED,6X25

130B0625

Unavailable

130A

BOLT-FLANGED,6X18

130G0618

Unavailable

480

CIRCLIP-TYPE-C,24MM

480J2400

$4.98

654

OIL SEAL,#50659

654A506509

Unavailable
