Kawasaki Jet Ski® STX Handle Pole Diagram

Description

Price

11047

BRACKET,HANDLE HOLDER

11047-3759

$110.16

11061

GASKET,HANDLE POLE BRACKET

11061-3735

$65.02

13270

PLATE,STEERING NUT

13270-3808

$7.58

14091

COVER,HANDLE POLE BRACKET

14091-3733

$7.49

39021

BRACKET-HANDLE POLE

39021-3714

$304.80

39117

SHAFT-STRG

39117-3713

$308.62

59266

JOINT-BALL

59266-3707

$59.33

92015

NUT,CASTLE,14MM

92015-3805

$36.18

92015A

NUT,STEERING,20MM

92015-3854

Unavailable

92022

WASHER,15X34X2.0

92022-3738

$4.93

92022A

WASHER,8.4X23X2.5

92022-3744

$3.19

92028

BUSHING,STEERING

92028-3748

$24.03

92039

RIVET,4.8MM

92039-3719

$5.42

92150

BOLT,FLANGED,8X30

92150-3803

$5.61

92200

WASHER,32.5X70X2

92200-3718

$15.76

120

BOLT-SOCKET,5X10

120R0510

$3.01

317

NUT

317R0800

$1.42

411

WASHER-PLAIN,5MM

411S0500

$0.78

550

PIN-COTTER,3X35

550S3035

$4.02
