2020 Kawasaki JET SKI® STX®160X Handlebar Diagram

← All diagrams

Find the part on the Handlebar diagram for your 2020 Kawasaki JET SKI® STX®160X, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2020 Kawasaki JET SKI® STX®160X Handlebar Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

13151

SWITCH-COMP

13151-0587

1
Out of stock

13151A

SWITCH-COMP,STOP&START

13151-3722

1
Out of stock

13236

LEVER-COMP,THROTTLE

13236-0820

1
Out of stock

14093

COVER,HOLDER,FR

14093-0900

1
Out of stock

14093A

COVER,HOLDER,RR

14093-0901

1
Out of stock

155

BOLT-WSP-SMALL,8X40

155R0840

1
Out of stock

220

SCREW-PAN-CROS,5X14

220R0514

1
Out of stock

220A

SCREW-PAN-CROS,5X25

220R0525

1
Out of stock

39058

HANDLE-COMP,F.BLACK

39058-0041-6Z

1
Out of stock

39087

PAD-HANDLE,GRAY

39087-0014-66L

1
Out of stock

39156

PAD,INNER

39156-2457

1
Out of stock

411

WASHER-PLAIN,6MM

411S0600

1
Out of stock

46012

HOLDER-HANDLE

46012-0394

1
Out of stock

46012A

HOLDER-HANDLE,UPP

46012-3720

1

$15.76

In stock

92002

BOLT,8X25

92002-3774

1
Out of stock

92009

SCREW,5X30

92009-3836

1
Out of stock

92022

WASHER,6.5X20X1.5

92022-3710

1
Out of stock

92072

BAND,L=188.85

92072-0105

1
Out of stock

92072A

BAND,TETHER SWITCH

92072-3809

1
Out of stock

92154

BOLT,SOCKET,6X14

92154-3988

1
Out of stock

92192

TUBE,35X37X200

92192-1990

1
Out of stock
