2010 Kawasaki Jet Ski® STX-15F Handle Pole Diagram

← All diagrams

Find the part on the Handle Pole diagram for your 2010 Kawasaki Jet Ski® STX-15F, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2010 Kawasaki Jet Ski® STX-15F Handle Pole Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

11047

BRACKET,HANDLE HOLDER

11047-3759

1
Out of stock

11061

GASKET,HANDLE POLE BRACKET

11061-3735

1
Out of stock

13091

HOLDER

13091-3809

1

$77.21

In stock

13107

SHAFT

13107-3751

1
Out of stock

13168

LEVER,REVERSE

13168-3750

1
Out of stock

13270

PLATE,STEERING NUT

13270-3808

1

$6.13

In stock

13320

LEVER-ASSY,REVERSE

13320-3716

1

$231.05

In stock

39021

BRACKET-HANDLE POLE

39021-3714

1

$304.80

In stock

39117

SHAFT-STRG

39117-3713

1

$308.62

In stock

59266

JOINT-BALL

59266-3707

1
Out of stock

92015

NUT,FLANGED,8MM

92015-3709

1
Out of stock

92015A

NUT,CASTLE,14MM

92015-3805

1
Out of stock

92015B

NUT,CASTLE,8MM

92015-3813

1
Out of stock

92015C

NUT,STEERING,20MM

92015-3854

1
Out of stock

92022

WASHER,15X34X2.0

92022-3738

1
Out of stock

92022A

WASHER,15.5X24X1.5

92022-3739

1
Out of stock

92022B

WASHER,8.4X23X2.5

92022-3744

1
Out of stock

92028

BUSHING,STEERING

92028-3748

1
Out of stock

92028A

BUSHING

92028-3755

1
Out of stock

92033

RING-SNAP,15MM

92033-3710

1
Out of stock

92066

PLUG,REVERSE LEVER

92066-3761

1
Out of stock

92150

BOLT,FLANGED,8X30

92150-3803

1
Out of stock

92200

WASHER,32.5X70X2

92200-3718

1
Out of stock

92210

NUT,8MM

92210-3703

1
Out of stock

120

BOLT-SOCKET,5X10

120R0510

1
Out of stock

120A

BOLT-SOCKET,6X16

120R0616

1
Out of stock

317

NUT

317R0800

1
Out of stock

550

PIN-COTTER

550S2020

1
Out of stock

550A

PIN-COTTER,3X35

550S3035

1
Out of stock
