Sea-doo GTI LE, 2004 Oil System Diagram

#

Description
Price

1

Oil Tank

275000238

Unavailable

2

OIL 2T CARB PREM. MINERAL QT/0,946L This part replaces 413802900.

779119

Unavailable

2

2T Snowmobile Premium Mineral Oil This part replaces 413803000.

779120

Unavailable

2

OIL 2T CARB PREM. MINERAL 55 GAL/205L This part replaces 413803200.

779123

Unavailable

3

Filler Hose

275000188

Unavailable

4

Tridon Clamp

293650035

Unavailable

5

FILLER NECK - Call your local BRP dealership

275000242

Unavailable

6

Gasket

293250132

Unavailable

7

Nut-Neck Oil Filler

211100013

Unavailable

8

Oil Cap

275000186

Unavailable

9

Oil Tank Cap

275000199

Unavailable

10

O-RING - Call your local BRP dealership

293250025

Unavailable

11

Pop Rivet 1/8"

390407900

Unavailable

12

Flat Washer M3, Stainless

234032600

Unavailable

13

OIL LEVER SENSOR ASS'Y - Call your local BRP dealership

278001401

Unavailable

14

Wire Seal

278000218

Unavailable

15

Male Terminal | XT Models

278000222

Unavailable

16

Female Housing, 2 Circuits

278000217

Unavailable

17

Grommet

293720008

Unavailable

18

Was 275500549 Hose 1/4"

219704357

Unavailable

19

Tie Wrap 142 mm

293750002

Unavailable

20

Was 275500008 Hose 12 mm

219704356

Unavailable

21

Norma Clamp

293650084

Unavailable

22

Check Valve

275500398

Unavailable

23

Grommet

293720008

Unavailable

24

FITTING ELBOW 90 - Call your local BRP dealership

293710051

Unavailable

25

Polyurethane Hose, 8 Mm 3000Mm Long

219704412

Unavailable

26

Tie Wrap 94 mm | 4X4

293750001

Unavailable

27

OIL FILTER - Call your local BRP dealership

275000051

Unavailable

28

Oetiker Clamp

293650042

Unavailable

29

Was 293550004 Dielectric Grease, 150 g

219704453

Unavailable

30

Oil Cap Chain

275500015

Unavailable

31

Tubing 16 Mm 1000Mm Long

219704408

Unavailable
