1987 Suzuki GSXR50 Front Damper Diagram

← All diagrams

Find the part on the Front Damper diagram for your 1987 Suzuki GSXR50, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1987 Suzuki GSXR50 Front Damper Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

DAMPER ASSY, RH

51103-28B00

1
Out of stock

2

DAMPER ASSY, LH | Includes Item(s) 3 - 18

51104-28B00

1
Out of stock

3

TUBE, OUTER RH

51130-28B00

1
Out of stock

4

NO DESCRIPTION AVAILABLE This part replaces 51140-28B00.

51140-28B01

1
Out of stock

5

BOLT, CYLINDER

51147-16510

2
Out of stock

6

GASKET

51148-41310

2
Out of stock

7

CYLINDER

51146-28B00

2
Out of stock

8

SPRING

51177-35400

2
Out of stock

9

RING

51196-39140

2
Out of stock

10

OIL SEAL

51153-02501

2
Out of stock

11

RING, OIL SEAL STOPPER

51156-43010

2
Out of stock

12

SEAL, DUST

51173-28B00

2
Out of stock

13

TUBE, INNER

51110-28B00

2
Out of stock

14

SPRING

51171-28B00

2
Out of stock

15

WASHER

51172-27510

2
Out of stock

16

SPACER

51176-28B00

2
Out of stock

17

O-RING (D:2.4,ID:15.8) This part replaces 51181-23330.

09280-15007

2
Out of stock

18

NO DESCRIPTION AVAILABLE This part replaces 51351-03A00.

51351-28B00

2
Out of stock
