1987 Suzuki GSXR50 Carburetor Diagram

← All diagrams

Find the part on the Carburetor diagram for your 1987 Suzuki GSXR50, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1987 Suzuki GSXR50 Carburetor Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

CARBURETOR ASSY | Includes Item(s) 1 - 30

13200-28B00

1
Out of stock

1

SCREW, THROTTLE STOP

13483-16A01

1
Out of stock

2

SPRING

13268-35010

2
Out of stock

3

WASHER

13291-35010

1
Out of stock

4

O RING

13295-33010

1
Out of stock

5

JET, MAIN (80)

09491-80011

1
Out of stock

6

JET, NEEDLE (E-5)

09494-00538

1
Out of stock

7

NEEDLE, JET | 3N17-2

13383-28B00

1
Out of stock

8

FLOAT

13250-02500

1
Out of stock

9

PIN, FLOAT

13254-20010

1
Out of stock

10

VALVE ASSY, NEE This part replaces 13370-03A40.

13370-31C80

1
Out of stock

11

PLATE

13373-46710

1
Out of stock

12

SCREW This part replaces 02112-03086.

02112-0308A

1
Out of stock

13

JET, PILOT (15)

09492-15010

1
Out of stock

14

GASKET, FLOAT CHAMBER

13251-02410

1
Out of stock

15

SPRING

13573-02330

1
Out of stock

16

SEAT, SPRING

13581-04010

1
Out of stock

17

E RING This part replaces 13394-12110.

13394-40D00

1
Out of stock

18

VALVE, THROTTLE (OA:2.0) This part replaces 13551-28B00.

13551-02330

1
Out of stock

19

SCREW

13601-04148

4
Out of stock

20

SCREW, DRAIN

13247-24500

1
Out of stock

21

O RING

13278-02340

1
Out of stock

22

SCREW, PILOT AIR | 1 7/8

13269-29900

1
Out of stock

23

WASHER This part replaces 13277-44080.

13291-29900

1
Out of stock

24

O-RING This part replaces 13295-29900.

13295-29901

1
Out of stock

25

PLUNGER, STARTER

13411-01010

1
Out of stock

26

CAP, STARTER

13418-43200

1

$11.83

In stock

27

O RING

13278-02330

1
Out of stock

28

SPRING

13417-37200

1
Out of stock

29

HOSE This part replaces 13684-44A00.

09351-30001-600

1
Out of stock

30

HOSE (3X5X475)

13683-28B00

1
Out of stock
