Suzuki GSX1300R (2007) EVAP SYSTEM (E33) Diagram

#

Description
Price

1

NO DESCRIPTION AVAILABLE This part replaces 44434-24F00.

44400-19810

Unavailable

2

SPRING

09440-13041

$3.56

3

CLIP

09401-11413

$2.24

4

VALVE FUEL TANK BREATHER

44240-17C00

$73.01

5

PLATE, BREATHER VALVE | Includes Item(s) 6

44890-24F00

Unavailable

6

CUSHION (10X30X2)

44894-24A00

$1.78

7

SCREW, PLATE

02142-0610B

$2.35

8

PLATE,FUEL TANK BREATHER NO.2 | Includes Item(s) 9

44892-24A00

$5.10

9

CUSHION (10X30X2)

44894-24A00

$1.78

10

SCREW

02142-0408B

$1.71

11

HOSE, 2 WAY VALVE & BREATHER VALVE | L:600!320

09355-54116-600

$11.04

12

SPRING

09440-13051

$9.85

13

VALVE, 2 WAY & CANISTER

44240-24F00

$73.01

14

WASHER

09160-06152

$2.57

15

BOLT

01550-0616B

$2.53

16

CANISTER ASSY CHARCOAL

17210-26E00

$360.67

17

CAP

09251-07003

$2.77

18

CUSHION CANISTER

44883-26E00

Unavailable

19

BRACKET, CANISTER

44880-24F00

Unavailable

20

BOLT, BRACKET

01550-0612B

$2.38

21

HOLDER, CANISTER

44882-26E00

Unavailable

22

SCREW, HOLDER

02142-0610B

$2.35

23

HOSE, CANISTER & 2 WAY VALVE | L:600!130

09355-54116-600

$11.04

24

SPRING

09440-13041

$3.56

25

HOSE, CANISTER & CARB

09359-54111-600

$28.05

26

SPRING

09440-13053

Unavailable

27

CLIP

09401-12404

$2.37

28

UNION

09364-06005

$6.22
