COWLING FITTING SET (OPTIONAL)
1993 Suzuki GSX1100G Cowling Fitting SET Diagram
Find the part on the Cowling Fitting SET diagram for your 1993 Suzuki GSX1100G, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.
#
1
FULL COWLING SET GSX110OGM (GRAY)
94000-26810-1AC
1
FULL COWLING SET GSX110OGN/GP (BLACK)
94000-26810-13Z
1
FULL COWLING SET GSX110OGM/GN/GP (MAROON)
94000-26810-20F
1
SCREW, SCREEN (6X25)
09139-06029
3
BRACE, SCREEN
94500-26D50
5
BOLT (8X16) This part replaces 01517-08165.
01550-0816A
6
BRACE, COWLING
94510-26D50
7
BOLT (8X16) This part replaces 01517-08165.
01550-0816A
11
SCREW, SCREEN (5X20)
03242-05205
12
WASHER (5.2X11.0X1.0)
09161-05010
14
SHADE, HEADLAMP
35129-26D50
15
CLAMP, SHADE
35189-26D50
21
NUT COWL This part replaces 94484-32B00.
94484-24F00
22
SCREW, BODY REAR (6X20)
09139-06028
25
CUSHION
09320-09016
26
BRACE, BODY REAR RH
94453-26D50
27
BRACE, BODY REAR LH
94454-26D50
28
BOLT, NO.3 This part replaces 07110-06105.
07130-0610B
32
WASHER (5.2X11.0X1.0)
09161-05010
33
PLATE, HEAT GUARD RH
94555-26D50
34
PLATE, HEAT GUARD LH
94556-26D50
35
BOLT, NO.3 This part replaces 07110-06105.
07130-0610B
40
PLATE, UNDER
94493-06B00
41
SCREW, UNDER (6X20)
09139-06028
44
CUSHION
09320-09016
45
BRACE, LOWER RH
94551-26D50
46
BRACE, LOWER LH
94552-26D50
47
BOLT | FIG.35, NO.13 This part replaces 07110-08605.
07130-0860B
49
SCREW, PANEL (5X20)
03242-05205
52
WIRE, TURNSIGNAL LH This part replaces 36852-26D00.
36852-26D10
53
WIRE, TURNSIGNAL LH
36852-26D10
54
CLAMP (L:82) This part replaces 09404-10403.
09404-10205
54
CLAMP, CLUTCH HOSE
09407-14403
54
CLAMP, WIRE HARNESS
09407-14403
55
WASHER
08322-11046
56
PLUG, HEADLAMP
35165-26D50
