Ski-Doo GSX SPORT 500SS, 2008 Magneto Diagram

#

Description

Price

1

Not Available As Spare Part - Friction Washer

Unavailable

2

Stator Plate | Includes 2 to 3

420889904

$319.49

3

Flywheel

420665722

$516.89

4

Pickup Ass'y

420966804

$206.12

5

Socket Head Screw M6 X 30

205063044

Unavailable

6

Torx Screw M6 X 16

420640324

$2.06

7

Starting Pulley

420852590

$28.43

8

Flat Washer

420827405

$1.66

9

Socket Head Screw M8 X 12

420841520

$1.68

10

Tube

420460871

$2.06

11

Conduit Clip

420960896

$2.14

B

Loctite 243, 10 ml

293800060

$20.77

P

Loctite 5910, 300 ml

293800081

$57.99
