Description

Price

1

RELAY ASSY,STARTING MOTOR This part replaces 31800-06G00.

31800-06G02

$64.39

2

FUSE (30A)

09481-30101

$2.35

3

COVER, STARTER

31861-47E00

$18.23

4

SCREW (6X8)

09128-06013

$1.28

5

RECTIFIER ASSY

32800-47H00

$250.53

6

BRACKET, RECTIFIER

32830-14J00

$19.32

7

SPACER (6.2X8.4X6.9)

09180-06325

$3.59

8

CUSHION (8.4X18X6)

09320-08066

$7.67

9

BOLT (6X20)

09116-06182

$2.33

10

BOLT

01550-0616A

$2.01

11

CLAMP(L:80) This part replaces 09404-06433.

09404-06036

$1.81

12

NUT

08316-1006A

$2.25

13

COIL ASSY,IGNITION

33410-38H00

$195.83

14

CONTROL UNIT,FI This part replaces 32920-15J90.

32920-15J91

$1,517.50

15

SENSOR ASSY,FUEL CUT

33960-27G00

$124.02

16

ACTUATOR ASSY This part replaces 33970-47H01.

33970-47H03

$465.78

17

BOLT (6X32.5)

09116-06148

$3.00

Suzuki GSX-R750L3 (2013) ELECTRICAL (E33) Diagram
