Suzuki GSX-R1000 (2008) RADIATOR Diagram

#

Description
Price

1

RADIATOR ASSY, WATER

17710-21H00

$1,267.58

2

CAP, RADIATOR This part replaces 17730-12C20.

17730-08J00

$40.65

3

BOLT (6X20)

09118-06097

$2.57

4

SPACER

09180-06290

$2.09

5

CUSHION

09320-10051

$2.91

6

FAN ASSY, RADIATOR

17800-21H00

Unavailable

7

BOLT

17711-40F00

$6.30

8

NUT, FAN ASSY

17712-40F00

$4.61

9

BRACKET, RADIATOR & OIL COOLER

17750-41G00

$8.88

10

BOLT

01550-0612A

$2.01

11

BRACKET, RADIATOR SUPPORT

17790-21H00

$39.10

12

BOLT

01550-0610A

$2.01

13

SHIELD, RADIATOR HEAT

17771-21H00

Unavailable
