Suzuki GSX-R1000 (2004) LABEL Diagram

#

Description
Price

1

LABEL,GENERAL W | E3,E28,E33 This part replaces 68319-29F00.

68319-29F01

$7.51

1

LABEL, WARNING (FRENCH) | E28

68319-29F30

Unavailable

2

LABEL,SCREEN | E3,E28,E33 This part replaces 68922-29F00.

68922-29F01

$7.27

2

LABEL, SCREEN (FRENCH) | E28

68922-29F30

Unavailable

3

LABEL,MANUAL NOTICE | E3,E33 This part replaces 68353-26E02.

68353-26E03

$4.63

4

LABEL, TIRE | E3,E33

68332-18G10

Unavailable

4

LABEL, TIRE | E28

68332-18G00

Unavailable

5

LABEL,WARNING S | E3,E33 This part replaces 68613-18E00.

68613-18E01

$8.45

5

LABEL,WARNING S | E28 This part replaces 68613-24F00.

68613-24F01

$10.85

6

LABEL, ROUTING | E33

68387-18G00

Unavailable

7

LABEL, FUEL | E3,E33

18803-02F01

Unavailable

7

LABEL, FUEL | E28

18803-40F10

$5.42

8

MANUAL, OWNER'S (ENGLISH) | MODEL K3 E3,E33

99011-40F60-03A

Unavailable

8

MANUAL, OWNER'S (ENGLISH) | MODEL K3 E28

99011-40F60-01A

Unavailable

8

MANUAL, OWNER'S (FRENCH) | MODEL K3 E28

99011-40F51-01F

Unavailable

8

MANUAL, OWNER'S (ENGLISH) | MODEL K4 E3,E33

99011-40F61-03A

$24.15

8

MANUAL, OWNER'S (ENGLISH) | MODEL K4 E28

99011-40F61-01A

Unavailable

8

MANUAL, OWNER'S (FRENCH) | MODEL K4 E28 DRAWING NOT SHOWN

99011-40F61-01F

Unavailable
