Ski-Doo GSX LTD 600 HO SDI, 2008 Front Arm Diagram
#
Description
Price
1
Stopper Strap
503192360
Unavailable
2
Hex. Flange Screw M8 X 30 | DS 650 X
207683044
Unavailable
4
Hex. Flange Elastic Nut M8
233281414
Unavailable
5
Axle Strap
503191260
Unavailable
6
Spacer
503191448
Unavailable
8
Washer
503189564
Unavailable
9
Rocker Arm
503191161
Unavailable
11
Center Shaft
503191764
Unavailable
12
LONG BOLT - Call your local BRP dealership
503191352
Unavailable
14
Washer
732900049
Unavailable
15
Center Bushing
503191351
Unavailable
16
Swivel Bushing
503191555
Unavailable
17
Front Arm Ass'y | Includes 2000 to 2000b
503191579
Unavailable
18
Bushing
503191554
Unavailable
19
Lower Axle
503191966
Unavailable
20
Washer
503190656
Unavailable
22
Washer
503189276
Unavailable
23
Axle
503190698
Unavailable
24
HEX. SCREW M10 X 60 - Call your local BRP dealership
207006084
Unavailable
25
Washer
503189564
Unavailable
28
Link Rod
503191802
Unavailable
30
Hex. Flange Screw
207688544
Unavailable
31
Hex. Flange Elastic Nut M8
233281414
Unavailable
32
Bushing
503191553
Unavailable
33
Plastic Spacer
503190694
Unavailable
34
Bushing
414936000
Unavailable
35
Hex. Flange Screw M8 X 40
207684044
Unavailable
36
Hex. Flange Elastic Nut M8
233281414
Unavailable
37
Hex. Screw M10 X 1.5 X 50
207005044
Unavailable
39
Central Shock Axle
503190604
Unavailable
40
Hex. Flange Screw M10 X 75
207607544
Unavailable
