1979 Suzuki GS850G Transmission Diagram

← All diagrams

Find the part on the Transmission diagram for your 1979 Suzuki GS850G, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1979 Suzuki GS850G Transmission Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

NO DESCRIPTION AVAILABLE This part replaces 24121-45102.

24121-45103

1
Out of stock

2

COUNTERSHAFT, OUTER | NT:14 This part replaces 24141-45101.

24141-45102

1
Out of stock

3

GEAR, 2ND DRIVE (NT:18) | NT:18 This part replaces 24221-45101.

24221-45102

1
Out of stock

4

WASHER | 21x35x2

09160-21010

1
Out of stock

5

GEAR, 5TH DRIVE (NT:26) | NT:26 This part replaces 24250-45101.

24250-45102

1
Out of stock

6

RING

09380-32002

1
Out of stock

7

SPACER | 32x36x13.4

24242-45100

1
Out of stock

8

LOCK WASHER

24243-45101

1
Out of stock

9

NO DESCRIPTION AVAILABLE | NT:21 This part replaces 24231-45102.

24231-45104

1
Out of stock

10

GEAR, 4TH DRIVE | NT:24

24240-45100

1
Out of stock

11

RING

09380-32002

1
Out of stock

12

SPACER | 32x36x13.4

24242-45100

1
Out of stock

13

LOCK WASHER

24243-45101

1
Out of stock

14

BEARING, LH This part replaces 09262-25051.

09262-25105

1
Out of stock

15

C RING This part replaces 09390-62006.

09390-62012

1
Out of stock

16

MOLDER, BEARING

24741-45000

1
Out of stock

17

SCREW This part replaces 02122-06168.

02122-06167

3
Out of stock

18

BEARING, MIDDLE

09262-32003

1
Out of stock

19

C RING

09390-52004

1
Out of stock

20

OIL SEAL

09283-40005

1
Out of stock

21

DOG, OUT PUT CAM

22521-45101

1
Out of stock

22

OIL SEAL

09283-20032

1
Out of stock

23

CIRCLIP This part replaces 08331-21329.

08331-41329

1
Out of stock

24

DOG, INPUT CAM

22511-45102

1
Out of stock

25

SPRING

09440-35002

1
Out of stock

26

SLIDING STOPPER This part replaces 22531-45100.

22531-45101

1
Out of stock

27

STOPPER

22541-45100

2
Out of stock

28

GUIDE, SPRING

22551-45101

1
Out of stock

29

BEARING, DRIVE SHAFT RH This part replaces 09262-17008.

09262-17023

1
Out of stock

30

SPACER | 17x21x3.5

09180-17052

1
Out of stock

31

PLUG

09241-40003

1
Out of stock

32

NO DESCRIPTION AVAILABLE This part replaces 24131-45102.

24131-45104

1
Out of stock

33

GEAR, 1ST DRIVEN | NT:35

24310-45100

1
Out of stock

34

WASHER, LH

08211-25383

1
Out of stock

35

WASHER, RH | T:1

09167-28001

1
Out of stock

36

CIRCLIP This part replaces 08331-11289.

08331-31289

1
Out of stock

37

GEAR, 4TH DRIVEN | NT:27

24341-45100

1
Out of stock

38

GEAR 3RD DRIVEN | NT:29 This part replaces 24331-45100.

24331-49202

1
Out of stock

39

BUSHING

24332-49000

1
Out of stock

40

WASHER | T:1

09167-28001

1
Out of stock

41

CIRCLIP This part replaces 08331-11289.

08331-31289

1
Out of stock

42

LOCK WASHER, RH | T:1

09169-28001

1
Out of stock

43

WASHER, RH | T:1.5

09167-28002

1
Out of stock

44

GEAR, 5TH DRIVEN (NT:25) | NT:25 This part replaces 24351-45101.

24351-45104

1
Out of stock

45

GEAR, 2ND DRIVEN (NT:32) | NT:32 This part replaces 24320-45100.

24320-45102

1
Out of stock

46

WASHER

08211-20341

1

$3.05

In stock

47

BEARING, RH

09262-20049

1
Out of stock

48

C RING

09390-47003

1
Out of stock

49

CIRCLIP

09380-20007

1
Out of stock

50

PLATE, ORIVESHAFT

24761-45100

1
Out of stock

51

GASKET,DR SHFT This part replaces 24762-45000.

24762-45000-H17

1
Out of stock

52

SCREW This part replaces 02122-06168.

02122-06167

4
Out of stock

53

BEARING This part replaces 09262-25055.

09262-25030

1
Out of stock

54

C RING

09390-52002

1
Out of stock

55

OIL SEAL

09283-35015

1
Out of stock

56

SPACER | 25x35x14

24136-45100

1
Out of stock
