Suzuki GS750L (1981) RIGHT HANDLE SWITCH Diagram

#

Description
Price

1

GRIP ASSY, THROTTLE | MODEL T; Includes Item(s) 2 - 6 This part replaces 57100-47011.

57100-47500

Unavailable

2

GRIP, THROTTLE | MODEL T This part replaces 57110-44011.

57110-49510

Unavailable

3

BUTTON, STARTER | MODEL T

57371-45000

$5.10

4

CONTACT | MODEL T

57372-45000

$5.02

5

SPRING | MODEL T

57382-45000

$3.80

6

SCREW | MODEL T This part replaces 02112-05258.

02112-05257

$1.49

7

GRIP, THROTTLE | MODEL X This part replaces 57110-44011.

57110-49510

Unavailable

8

GRIP ASSY, THROTTLE | MODEL X; Includes Item(s) 9 - 12 This part replaces 57100-44130.

57100-47500

Unavailable

9

BUTTON, STARTER | MODEL X

57371-45000

$5.10

10

CONTACT | MODEL X

57372-45000

$5.02

11

SPRING | MODEL X

57382-45000

$3.80

12

SCREW | MODEL X This part replaces 02112-05258.

02112-05257

$1.49

13

CAP, GRIP END RH

57215-49100

Unavailable

14

LEVER, BRAKE | Includes Item(s) 15 - 17 This part replaces 57300-49101.

57420-49101

$31.26

15

LEVER, BRAKE

57420-49101

$31.26

16

BOLT

57431-18621

$9.35

17

.NUT This part replaces 08319-21063.

08319-2106B

$2.31

18

SWITCH ASSY, ST | Includes Item(s) 19 - 25 This part replaces 57460-49100.

57460-45500

$33.16

19

HOLDER This part replaces 57461-18600.

57465-18601

$3.97

20

HOLDER This part replaces 57462-18600.

57465-18601

$3.97

21

HOLDER This part replaces 57463-18600.

57465-18601

$3.97

22

COVER

57481-33010

$5.50

23

SCREW This part replaces 09125-03105.

09125-03105-XC0

$2.08

24

WASHER,LOCK This part replaces 08321-21038.

09162-03001

$1.18

25

WASHER This part replaces 08322-21038.

08322-01037

$1.95

26

BAND (L:120)

09407-12402

$2.80
