1982 Suzuki GS450T Air Cleaner Diagram

← All diagrams

Find the part on the Air Cleaner diagram for your 1982 Suzuki GS450T, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1982 Suzuki GS450T Air Cleaner Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

NO DESCRIPTION AVAILABLE | Includes Item(s) 2 - 11 This part replaces 13700-44100.

13700-44102

1
Out of stock

2

FILTER

13781-44100

1
Out of stock

3

HOLDER, FILTER

13792-44100

1
Out of stock

4

HOSE, OUTLET RH

13881-44100

1
Out of stock

5

HOSE, OUTLET LH

13882-44100

1
Out of stock

6

CLAMP

09402-60305

—
Out of stock

7

CAP

13740-44100

1
Out of stock

8

1

$15.91

In stock

9

1

$52.55

In stock

10

2

$2.50

In stock

11

SLIDER

13821-00011

2

$2.92

In stock

12

CUSHION (8.5X20X8) This part replaces 09320-08007.

09320-08510

4
Out of stock

13

SPACER

09180-06038

4

$2.16

In stock
