1983 Suzuki GS450GA Left Handle Switch Diagram

← All diagrams

Find the part on the Left Handle Switch diagram for your 1983 Suzuki GS450GA, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1983 Suzuki GS450GA Left Handle Switch Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

GRIP, LH

57211-44500

1
Out of stock

2

LEVER ASSY, PARKING BRAKE | Includes Item(s) 3 - 15 This part replaces 57500-44500.

57500-44501

1
Out of stock

3

LEVER, PARKING

57620-44500

1
Out of stock

4

BOLT This part replaces 57431-11011.

57431-11013

1
Out of stock

5

.NUT This part replaces 08319-21068.

08319-2106A

1
Out of stock

6

HOLDER

57465-18601

1
Out of stock

7

WIRE - HARNESS

57541-44500

1
Out of stock

8

COVER

57481-33010

1
Out of stock

9

SCREW This part replaces 09125-03105.

09125-03105-XC0

2
Out of stock

10

WASHER,LOCK This part replaces 08321-21038.

09162-03001

2
Out of stock

11

WASHER This part replaces 08322-21038.

08322-01037

2
Out of stock

12

ADJUSTER, CABLE

57441-44400

1

$8.33

In stock

13

NUT This part replaces 57442-44400.

57442-11010

1
Out of stock

14

BOLT

57451-49100

1
Out of stock

15

HOLDER

57512-44500

1
Out of stock

16

NO DESCRIPTION AVAILABLE | Includes Item(s) 17 - 21 This part replaces 37400-44522.

37400-44523

1
Out of stock

17

SCREW This part replaces 02112-05168.

02112-05167

2
Out of stock

18

BODY

37572-49441

1
Out of stock

19

WASHER

58722-03010

1
Out of stock

20

LEVER

58721-27503

1
Out of stock

21

SCREW This part replaces 37574-49440.

02112-7516A

1
Out of stock

22

BAND (L:120)

09407-12402

1
Out of stock
