Suzuki GS450ET (1982) FRONT FORK (MODEL T Diagram

#

Description
Price

1

DUMPER ASSY, RH

51103-44100

Unavailable

2

DUMPER ASSY, LH | Includes Item(s) 3 - 25

51104-44100

Unavailable

3

OUTER TUBE, RH

51130-44033

Unavailable

4

OUTER TUBE, LH

51140-44031

Unavailable

5

SPACER, SEAL

51168-44030

$5.90

6

OIL SEAL This part replaces 51153-37310.

51153-02B00

$18.89

7

RING, OIL SEAL STOPPER This part replaces 51156-33130.

51156-02B00

$5.04

8

DUST SEAL

51571-37310

$18.98

9

INNER TUBE

51110-44030

Unavailable

10

.PIECE, OIL LOCK

51195-48000

Unavailable

11

CYLINDER This part replaces 51146-44031.

51146-38300

Unavailable

12

SPRING, REBOUND

51177-36030

Unavailable

13

O RING This part replaces 51148-31030.

51148-36011

$3.26

14

BOLT

51147-48130

$3.97

15

RING, PISTON

51196-33130

$9.17

16

SPRING

51171-44100

Unavailable

17

O RING

51181-31030

$4.11

18

BOLT

51351-33130

Unavailable

19

BOLT,STUD This part replaces 01421-08258.

01421-0825A

$2.01

20

HOLDER, AXLE

51132-31030

Unavailable

21

WASHER This part replaces 08322-21088.

08322-01087

$1.86

22

.LOCK WASHER This part replaces 08321-21088.

08321-01087

$1.83

23

NUT, CLUTCH RELEASE NO.1 This part replaces 09140-08005.

09140-08017

$2.12

24

SCREW This part replaces 02112-04068.

02112-0406B

$1.55

25

GASKET

51183-33030

Unavailable
