1979 Suzuki GS425L LH Handle Switch Diagram

← All diagrams

Find the part on the LH Handle Switch diagram for your 1979 Suzuki GS425L, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1979 Suzuki GS425L LH Handle Switch Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

GRIP, LH | L:130, OD:33 This part replaces 57211-44100.

57211-49500

1
Out of stock

2

CAP, GRIP AND LH

57216-49100

1
Out of stock

3

LEVER ASSY,CLUT | Includes Item(s) 4 - 14 This part replaces 57500-49110.

57500-49301

1
Out of stock

4

LEVER, CLUTCH This part replaces 57620-49110.

57620-49111

1
Out of stock

5

BOLT This part replaces 57431-11010.

57431-11013

1
Out of stock

6

.NUT This part replaces 08319-21068.

08319-2106A

1
Out of stock

7

ADJUSTER, CABLE

57441-11010

1
Out of stock

8

NUT

57442-11010

1
Out of stock

9

BOLT

57451-49100

1
Out of stock

10

HOLDER This part replaces 57461-18600.

57465-18601

1
Out of stock

11

HOLDER This part replaces 57462-18600.

57465-18601

1
Out of stock

12

HOLDER This part replaces 57463-18600.

57465-18601

1
Out of stock

13

COVER

57481-33010

1
Out of stock

14

SCREW This part replaces 09125-03105.

09125-03105-XC0

2
Out of stock

15

SWITCH ASSY, HANDLE LH | Includes Item(s) 16 - 24

37400-45603

1
Out of stock

16

KNOB, STOPPER

37414-45602

1
Out of stock

17

SCREW This part replaces 02122-03068.

02122-03067

1
Out of stock

18

KNOB, DIMMER SWITCH

37421-45012

1
Out of stock

19

SCREW This part replaces 02122-03068.

02122-03067

1
Out of stock

20

KNOB, TURN SIGNAL LAMP SWITCH

37513-45011

1
Out of stock

21

BUTTON, HORN

57371-45000

1
Out of stock

22

CONTACT

57372-45000

1
Out of stock

23

SPRING

57382-45000

1
Out of stock

24

SCREW This part replaces 02112-05258.

02112-05257

2
Out of stock

25

KNOB, LIGHTING | OPT

37411-45012

1
Out of stock
