1978 Suzuki GS400X AIR Cleaner Diagram

← All diagrams

Find the part on the AIR Cleaner diagram for your 1978 Suzuki GS400X, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1978 Suzuki GS400X AIR Cleaner Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

CLEANER ASSY, AIR | C,XC; Includes Item(s) 2 - 9

13700-44011

1
Out of stock

2

FILTER | C,XC

13780-44010

1
Out of stock

3

ELEMENT | C,XC

13781-44010

1
Out of stock

4

SCREW | C,XC This part replaces 02112-05108.

02112-05107

3
Out of stock

5

WASHER | C,XC This part replaces 08322-21058.

08322-01057

3
Out of stock

6

LOCK WASHER | C,XC This part replaces 08321-21058.

08321-0105A

3
Out of stock

7

HOSE, DRAIN | C,XC This part replaces 13791-44010.

13871-00020

1
Out of stock

8

CLIP | C,XC This part replaces 13795-44010.

09401-14301

1
Out of stock

9

..CLAMP | C,XC This part replaces 09402-60306.

09402-60208

2
Out of stock

10

SCREW | C,XC This part replaces 02112-06108.

02112-06107

3
Out of stock

11

WASHER | C,XC This part replaces 08322-21068.

08322-01067

3
Out of stock

12

BOLT | C,XC This part replaces 01107-06208.

01500-06207

1
Out of stock

14

SPACER (6.5X9X9) | C,XC; 6.1x9x9 This part replaces 09180-06011.

09180-06263

1
Out of stock

15

WASHER | C,XC; 6.5x18x1.6 This part replaces 09160-06007.

09160-06084

1
Out of stock

16

1

$2.28

In stock

17

HOSE,11X15X2000 | C,XC This part replaces 09343-11005.

09352-11154-00B

1
Out of stock

18

CLIP | C,XC

09401-14301

2
Out of stock

19

GASKET, CARBURETOR | C,XC

13125-44001

2
Out of stock

20

INSULATOR | C,XC

13129-44001

2
Out of stock

21

PIPE, INTAKE | C,XC

13110-44001

2
Out of stock

22

O-RING (D:2.4,ID:39.7) | C,XC This part replaces 09280-40003.

09280-40020

2
Out of stock

23

BOLT | C,XC This part replaces 01107-06358.

64455-07L00

4
Out of stock

24

4

$2.28

In stock

25

CLAMP | C,XC

09402-54303

2
Out of stock

26

CLAMP | C,XC

09402-58306

2
Out of stock

27

CLAMP | C,XC; L:180 This part replaces 09407-18301.

09407-18302

1
Out of stock
