Suzuki GS1100E (1981) CRANKCASE COVER Diagram

#

Description
Price

1

COVER, CLUTCH This part replaces 11340-49200.

11340-49201

Unavailable

2

GASKET,CLUTCH C This part replaces 11482-49201.

11482-49202-H17

$31.48

3

PIN

04211-09129

$1.64

4

SCREW (6X40) This part replaces 02112-06408.

02112-06407

$1.80

5

SCREW This part replaces 02112-06358.

02112-06357

$1.77

6

SCREW This part replaces 02112-06308.

02112-06307

$1.99

7

SCREW This part replaces 02112-06258.

02112-06257

$1.68

8

SCREW This part replaces 02112-06208.

02112-06207

$1.77

9

CAP, OIL FILLER This part replaces 09259-30001.

09200-30810

$9.15

10

O RING

09280-32005

$2.00

11

COVER, CONTACT BREAKER | MODEL T This part replaces 11381-49200.

11381-49202

$50.88

11

COVER, CONTACT BREAKER | MODEL X This part replaces 11381-49201.

11381-49202

$50.88

12

EMBLEM

68235-49200

$17.42

13

GASKET

11491-49200

Unavailable

14

SCREW This part replaces 02112-05308.

02112-0530A

$1.93

15

COVER, GENERATOR This part replaces 11351-49200.

11351-49201

Unavailable

16

EMBLEM

68233-49200

$17.77

17

GASKET,MAGNETO This part replaces 11483-49200.

11483-49210

$11.10

18

PIN This part replaces 09206-13001.

04211-13189

$2.19

19

SCREW (6X45) This part replaces 02112-06458.

02112-06457

$1.77

20

SCREW (6X40) This part replaces 02112-06408.

02112-06407

$1.80

21

SCREW This part replaces 02112-06358.

02112-06357

$1.77

21

SCREW This part replaces 02112-06308.

02112-06307

$1.99

22

COVER, ENGINE SPROCKET This part replaces 11360-49200.

11360-49201

Unavailable

23

PIN

04211-09129

$1.64

24

SCREW This part replaces 02112-06958.

02112-0695B

$4.03

25

SCREW This part replaces 02112-06858.

02112-06857

$2.64

26

SCREW This part replaces 02112-06708.

02112-06707

$2.55

27

SCREW (6x55)

02112-06557

$2.55

28

SCREW This part replaces 02112-06308.

02112-06307

$1.99

29

COVER, STARTER MOTOR

11382-49002

$52.35

30

BOLT This part replaces 01104-05108.

01500-0510B

$1.81

31

WASHER This part replaces 08322-21058.

08322-01057

$1.86
