Suzuki GS1000GL (1981) RIGHT HANDLE SWITCH Diagram

#

Description
Price

1

GRIP, THROTTLE This part replaces 57110-44011.

57110-49510

Unavailable

2

CAP, GRIP END RH | Includes Item(s) 3 - 5

57215-49100

Unavailable

3

LEVER, BRAKE

57420-49101

$32.45

4

BOLT

57431-18621

$9.35

5

.NUT This part replaces 08319-21068.

08319-2106A

$1.97

6

SWITCH ASSY, ST | Includes Item(s) 7 - 13 This part replaces 57460-49100.

57460-45500

$34.66

7

HOLDER This part replaces 57461-18600.

57465-18601

$4.15

8

HOLDER This part replaces 57462-18600.

57465-18601

$4.15

9

HOLDER This part replaces 57463-18600.

57465-18601

$4.15

10

COVER

57481-33010

$5.74

11

SCREW This part replaces 09125-03105.

09125-03105-XC0

$2.08

12

WASHER,LOCK This part replaces 08321-21038.

09162-03001

$1.22

13

WASHER This part replaces 08322-21038.

08322-01037

$2.01

14

BAND (L:120)

09407-12402

$2.82

15

SWITCH ASSY,HAN | Includes Item(s) 16 This part replaces 37200-49230.

37200-49232

Unavailable

16

SCREW This part replaces 37591-49210.

09125-05102

$1.61

17

SWITCH ASSY,HAN | OPT; Includes Item(s) 18 This part replaces 37200-49210.

37200-49212

Unavailable

18

SCREW | OPT This part replaces 37591-49210.

09125-05102

$1.61
