Ski-Doo Grand Touring V-1000, 2003 Crankshaft And Pistons Diagram

#

Description
Price

1

CRANKSHAFT ASS?Y - Call your local BRP dealership | Includes 1 to 4

420889441

Unavailable

1

Crankshaft

420889440

Unavailable

2

CONNECTING ROD ASS?Y - Call your local BRP dealership

420917546

Unavailable

3

Half-Bearing

420933523

Unavailable

4

Connecting rod Screw M10 X 1

420640991

Unavailable

5

TRIGGER WHEEL - Call your local BRP dealership

420966850

Unavailable

6

SOCKET HEAD SCREW M5 X 12 - Call your local BRP dealership

420640541

Unavailable

7

Drive Gear, 45 Teeth

420834445

Unavailable

8

Spring Washer

420245860

Unavailable

9

Nut

420242879

Unavailable

10

Piston Ass'y, Standard, 99.96 mm | Traxter 500 CVT, Includes 4 To 5

420296565

Unavailable

Piston Ass'y, Oversize, 100.21 mm | Traxter 500 CVT, Includes 4 To 5

420296566

Unavailable

11

Piston Set Ring, Standard | Traxter 500 CVT

420890380

Unavailable

Piston Set Ring, Oversize | Traxter 500 CVT & 650 CVT

420890381

Unavailable

12

Piston Pin

420216250

Unavailable

13

Circlip

420845580

Unavailable

14

Synth Oil 4T 12x1

293600054

Unavailable
