Ski-Doo Grand Touring 500, 1996 Front Arm 500, 580 Diagram

#

Description
Price

1

Grease Fitting

408200700

Unavailable

2

CUSHION - Call your local BRP dealership

414802600

Unavailable

3

Hex. Screw M8 X 40

207084044

Unavailable

4

Hex. Elastic Stop Nut M8

232581414

Unavailable

5

Welded Shock Support

503152100

Unavailable

6

Welded Front Arm

503167400

Unavailable

7

Hex. Screw M10 X 35

207103544

Unavailable

8

WASHER-LOCK SPRING DIN.128A-A2 - Call your local BRP dealership This part replaces 224701188.

234100602

Unavailable

9

SHAFT - Call your local BRP dealership

503190387

Unavailable

10

Cushion | Formula 500. Formula 500 Deluxe.

414894900

Unavailable

11

HEX. SCREW M10 X 60 - Call your local BRP dealership

207006044

Unavailable

12

Shock | Summit 500.

414975700

Unavailable

13

Cam

503169000

Unavailable

14

Center Spring | Touring SLE.

414976000

Unavailable

15

Protector

503193663

Unavailable

16

GUIDE_SPRING - Call your local BRP dealership

503165100

$1.91

17

Cap

706200785

Unavailable

18

Spring Stopper

706200881

$10.30

19

Axle

503151600

$15.35

20

Lock Washer 8 mm

234181401

Unavailable

21

Hex. Screw M8 X 30

207183044

Unavailable

22

Stopper Strap | Formula Z 583. Formula 583 Deluxe.

570038800

Unavailable

23

WASHER - Call your local BRP dealership

517078700

Unavailable

24

Shock

414975900

Unavailable

25

Axle Wheel | Formula 500. Formula 500 Deluxe.

503152800

Unavailable

26

Loctite 271, 10 ml

293800005

Unavailable

27

Hard Washer | Formula DLX 500 LC.

503007900

Unavailable

28

LITHIUM GREASE, 400 GR - Call your local BRP dealership | Skandic WT LC.

413706100

Unavailable

29

Flat Washer 10 mm

234001410

Unavailable
