1976 Yamaha GP440 Steering Gate Diagram

← All diagrams

Find the part on the Steering Gate diagram for your 1976 Yamaha GP440, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1976 Yamaha GP440 Steering Gate Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

STEERING GATE

(8A1-23870-00-00)

1
Out of stock

2

BOLT, HEXAGON

97027-08018-00

—

$1.62

In stock

3

WASHER, PLATE (1E7)

90201-08624-00

—
Out of stock

4

WASHER, LOCK 2

(861-23895-00-00)

1
Out of stock

5

FOOTREST 1

(8A1-27411-00-00)

1
Out of stock

6

FOOTREST 2

(8A1-27421-00-00)

1
Out of stock

7

SCREW, PAN

98507-06014-00

1

$6.18

In stock

8

YBS66-6 WASHER, PLAIN

92990-06200-00

1

$0.78

In stock

9

WASHER, PLAIN (646)

92990-06600-00

1

$2.48

In stock

10

WASHER, SPRING

92995-06100-00

1

$2.99

In stock

11

NUT, HEXAGON

95380-06600-00

1

$4.13

In stock

12

DAMPER, NOISE 11

(8A1-77271-00-00)

1
Out of stock

13

BOLT (661)

97013-06012-00

1

$4.71

In stock

14

WASHER, SPRING

92995-06100-00

1

$2.99

In stock

15

WASHER, PLATE

90201-06380-00

1

$0.57

In stock

16

BAND, SWITCH CORD

437-83936-11-00

—

$3.20

In stock
