Yamaha GP1300CB (GP1300R) F1G11 2003 ENGINE HATCH 1 Diagram

#

Description
Price

1

BOX, INDUCTION 1

F0X-62187-00-00

$116.65

2

BOX, INDUCTION 2

F0X-62188-00-00

$116.65

3

MAT, SIDE 1

F0X-6351C-00-00

$23.99

4

RIVET, BLIND

90267-48806-00

$2.00

5

COVER,SIDE 1

F0X-U377B-19-P1

Unavailable

6

COVER,SIDE 2

F0X-U377C-19-P1

Unavailable

7

SEAL

F1G-U2723-02-00

Unavailable

8

BOLT, HEXAGON SOCKET HEAD

90110-06008-00

Unavailable

9

WASHER

9299R-06200-00

$0.43

10

BRKT., COVER SIDE 1

F0X-6377M-00-00

$38.99

11

TAPE, FITTING

F0X-U3635-01-00

Unavailable

12

RIVET, BLIND

90267-48806-00

$2.00

13

BRACKET, COVER SIDE 3

F0X-6377P-00-00

Unavailable

14

SCREW

90149-05919-00

Unavailable
