Suzuki GN125Z (1983) FRONT FORK Diagram

#

Description
Price

1

OUTER TUBE RH | Includes Item(s) 1 - 34

51130-05300

Unavailable

2

OUTER TUBE LH

51140-05310

Unavailable

3

OIL SEAL

51153-05300

$16.98

4

RING, STOPPER

51156-41603

Unavailable

5

GASKET

51148-41310

$2.14

6

BOLT

51147-16510

$4.09

7

DUST SEAL

51173-41603

$10.82

8

PIECE, OIL LOCK

51195-36220

Unavailable

9

CYLINDER

51146-05300

Unavailable

10

INNER TUBE

51110-05300

Unavailable

11

SPRING

51171-05300

Unavailable

12

GUIDE, SPRING

51172-18630

Unavailable

13

SPACER

51176-05300

Unavailable

14

O RING This part replaces 51181-25010.

51181-29401

$3.80

15

CAP

51351-41603

Unavailable

16

STEM, STEERING This part replaces 51410-11310.

51410-11311

Unavailable

17

OUTER RACE

51621-33001

$18.33

18

STEM HEAD, STEERING

51311-11300-291

Unavailable

19

WASHER

51356-22012

$7.67

20

BOLT This part replaces 51351-20010.

51351-29400

$35.23

21

HOLDER, HANDLE

56211-29320-291

$14.60

22

BOLT

01204-08357

$2.10

23

LOCK WASHER This part replaces 08321-21068.

08321-01067

$1.83

24

BOLT This part replaces 51451-15113.

01104-10388

$1.78

25

LOCK WASHER This part replaces 08321-21108.

08321-01107

$1.83

26

CLIP

51455-36010

Unavailable

27

BOLT

51451-28012

Unavailable

28

LOCK WASHER This part replaces 08321-21128.

08321-01127

$2.07

29

CLIP

51453-05110

Unavailable

30

SCREW This part replaces 02112-06103.

02112-0610B

$1.83

31

LOCK WASHER This part replaces 08321-21068.

08321-01067

$1.83

32

BRACKET, HEADLAMP RH

51530-05300

Unavailable

33

BRACKET, HEADLAMP LH

51540-05300

Unavailable

34

CUSHION,HEADLAM This part replaces 51553-11300.

51553-11301

$4.63

35

COVER This part replaces 51871-05300.

51871-05301

Unavailable

36

EMBLEM

68211-38300

Unavailable
