1983 Suzuki FZ50 Headlamp Housing Diagram

← All diagrams

Find the part on the Headlamp Housing diagram for your 1983 Suzuki FZ50, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1983 Suzuki FZ50 Headlamp Housing Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

HOUSING, HEADLAMP (MAROON) | MODEL Z

51811-02430-10S

1
Out of stock

1

HOUSING, HEADLAMP (RED) | MODEL D

51811-02430-14C

1
Out of stock

2

BRACKET

51850-02401

1
Out of stock

3

BOLT This part replaces 01107-06208.

01500-06207

2
Out of stock

4

2

$2.28

In stock

5

SPACER

51821-02401

2
Out of stock

6

COVER FRAME HEA | MODEL Z This part replaces 51871-02401-10S.

51871-02401

1
Out of stock

6

COVER FRAME HEA | MODEL D This part replaces 51871-02401-14C.

51871-02401

1
Out of stock

7

CLIP

09409-06303

1
Out of stock

8

EMBLEM

68211-02400

1
Out of stock
