2014 Yamaha FX Nytro (FX10EB) Intake Diagram

← All diagrams

Find the part on the Intake diagram for your 2014 Yamaha FX Nytro (FX10EB), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2014 Yamaha FX Nytro (FX10EB) Intake Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

JOINT

8GL-13595-00-00

1

$16.69

In stock

2

HOSE CLAMP ASSY

90450-60004-00

1

$14.64

In stock

3

SILENCER, INTAKE 1

8GL-14431-00-00

—

$37.94

In stock

4

SILENCER, INTAKE 2

8GL-W1444-10-00

—
Out of stock

5

PLATE, ELEMENT

8GL-14472-00-00

1
Out of stock

6

ELEMENT, AIR CLEANER

8GL-14451-00-00

1

$8.31

In stock

7

HOOK

8GL-14436-00-00

1
Out of stock

8

DAMPER 1

8GL-14425-00-00

1
Out of stock

9

SEAL

8GL-14452-00-00

—

$3.49

In stock

10

PIPE

8GL-14419-00-00

1
Out of stock

11

JOINT, AIR CLEANER 1

8GL-14453-00-00

1

$25.32

In stock

12

GROMMET

90480-14198-00

1
Out of stock

13

HOSE CLAMP ASSY

90450-56007-00

1

$11.49

In stock

14

SENSOR, AIR TEMPERATURE

8FP-85886-00-00

1

$49.83

In stock

15

SCREW, PANHEAD TAPPING

97702-50520-00

1

$0.28

In stock

16

COLLER (6F5)

90387-08M45-00

—

$3.84

In stock

17

CLIP(34X)

90467-22097-00

—

$7.14

In stock

18

PIPE, OIL TANK BREATHER

8GL-21745-00-00

—

$40.46

In stock

19

HOLDER, GUIDE

8GL-14459-00-00

—

$2.15

In stock

20

JOINT, AIR CLEANER 2

8GL-14463-00-00

—

$28.28

In stock

21

JOINT

8GL-14454-00-00

—

$28.28

In stock

22

BOLT, WITH WASHER

90119-06231-00

—
Out of stock
