Find the part on the Windshield diagram for your 2011 Yamaha FX Nytro (FX10AW), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2011 Yamaha FX Nytro (FX10AW) Windshield Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

WINDSHIELD COMP.

8HL-K7210-00-00

1
Out of stock

2

. TRIM, UPPER

8HL-K7213-00-00

1
Out of stock

3

FAIRING 2

8HL-K723A-00-00

1
Out of stock

4

. TRIM 1

8HL-K7165-00-00

1
Out of stock

5

. TRIM 2

8HL-K7166-00-00

1
Out of stock

6

FAIRING 3

8HL-K723B-00-00

1
Out of stock

7

. TRIM 1

8HL-K7165-00-00

1
Out of stock

8

. TRIM 2

8HL-K7166-00-00

1
Out of stock

9

SCREW, ROUND HEAD(1UX)

90150-05024-00

1

$2.85

In stock

10

NUT(1KT)

90179-05523-00

1

$4.33

In stock

11

SCREW, ROUND HEAD(1UX)

90150-05023-00

1

$2.78

In stock

12

HEAD AND WASHER SET

99999-04116-00

1

$42.12

In stock

13

WASHER, PLATE(J38)

90202-07186-00

1

$8.08

In stock

14

WASHER, SPECIAL 1

5TJ-21757-00-00

1

$6.43

In stock
