Yamaha FJ09GS (FJ09) 2SCG0 2016 INTAKE Diagram

#

Description
Price

1

THROTTLE BODY ASSY

1RC-13750-01-00

Unavailable

2

HOSE, VACUUM SENSING 2

1RC-13544-00-00

Unavailable

3

. PIPE, JOINT 1

68V-24376-00-00

$13.59

4

HOSE, VACUUM SENSING 1

1RC-13542-00-00

Unavailable

5

PIPE

8FP-14349-20-00

$4.85

6

PIPE

8FP-14349-00-00

$9.65

7

NIPPLE

3XV-14251-00-00

$24.74

8

PIPE

8FP-14349-30-00

Unavailable

9

SCREW

2C0-14216-00-00

$2.98

10

SENSOR, PRESSURE

1WS-82380-00-00

$159.59

11

THROTTLE SENSOR AS

13S-85885-01-00

$114.75

12

SCREW

8CC-14216-10-00

$6.66

13

ACCELERATOR SENSOR

1MC-85884-01-00

$109.25

14

SCREW

5FL-14216-00-00

$3.64

15

PILOT SCREW SET

2C0-14105-00-00

$30.09
