Can-Am DS 250, CE, 2007 Front Fender Diagram

#

Description
Price

1

Shift Lever Cover

S46220RCA000

$5.97

2

Radiator Grille

S50611RCA000

$16.89

3

Grommet

S61105RCA000

$4.98

4

Front Fender Yellow

S6110GRCBK00ZY

$189.97

4a

LH FRONT FENDER DECAL - Call your local BRP dealership

S87134RCA000

Unavailable

4b

RH FRONT FENDER DECAL - Call your local BRP dealership

S87135RCA000

$11.71

4c

LH FRONT DECAL, DS 250 - Call your local BRP dealership

S87136RCA700

Unavailable

4d

RH FRONT DECAL, DS 250 - Call your local BRP dealership

S87137RCA700

Unavailable

4e

Warning Decal, Under 16 Years Old

S8750ARCA000

Unavailable

4f

Warning Decal, Death And Injury

S87501RCA000

Unavailable

5

Rubber Washer

S80103X01000

$4.98

6

Fender Collar

S80104X01000

$4.98

7

Fr.Rh.Side Fender

S83520RCA000JF

$18.43

8

LH Pannel

S83620RCA000JF

$18.43

9

Clip Nut

S90302V02000

$0.51

10

Tapping Screw M4 X 12

S9390332280

$0.40

11

DC Power Outlet, 12 Volts

S38600RA1000

$27.66

12

Radiator Cover

S64300RCA000

Unavailable

12a

BRP Logo

S87500RCA000

$36.89

12b

DS250 Decal

S87130RCA000

$10.98

13

Fuel Tank Cover

S43020RCA000

$20.74

14

Washer Bolt

S934040601407

$0.40

15

Special Screw

S90164RCA000

$0.91

16

Washer Bolt

S934040602507

$0.40

17

Tapping Screw

S9390344380

$0.40

18

Taping Screw M5 X 16

S9390345380

$0.88

19

Spring Washer 5 mm

S9411105800

$4.98
