Suzuki DR650SM (1991) LEFT HANDLE SWITCH Diagram

#

Description
Price

1

GRIP L

57211-12D00

$15.29

2

LEVER ASSY, CLUTCH | Includes Item(s) 3 - 9

57500-12D00

Unavailable

3

LEVER

57620-14310

$30.33

4

BOLT

57631-05D00

$8.03

5

.NUT This part replaces 08319-21068.

08319-2106A

$1.89

6

ADJUSTER

57441-11010

$5.14

7

NUT

57442-05D00

$9.25

8

SCREW, UPPER

02112-05164

$2.87

9

SCREW

09125-05066

$1.52

10

LEVER ASSY,DECO | Includes Item(s) 11 - 14 This part replaces 58700-38200.

58700-38210

$170.18

11

LEVER

58731-38200

$55.78

12

BOLT

57431-01012

$4.93

13

NUT

57633-38200

Unavailable

14

SCREW This part replaces 02112-06205.

02112-0620A

$1.45

15

COVER, DECOMP LEVER

57342-37101

Unavailable

16

SWITCH ASSY, HANDLE LH | Includes Item(s) 17

37400-14A60

Unavailable

17

.SCREW This part replaces 02112-05305.

02112-0530B

$1.45

18

COVER, KNUCKLE,LH (BLUE) This part replaces 57541-05D00-0NF.

57541-05D01-0NF

$52.15

19

SCREW

09125-05042

$1.98

20

WASHER (5.5X16X1.2) This part replaces 09160-05017.

09160-05043

$2.33

21

PLATE, COVER,LH

57542-05D00

$4.70

22

.NUT This part replaces 08319-21068.

08319-2106A

$1.89

23

SCREW This part replaces 09139-06010.

09139-06086

$3.42

24

LOCK WASHER This part replaces 08321-21067.

08321-01067

$1.83

25

BAND

09407-12402

$2.80
