Suzuki DR125 (1987) RIGHT HANDLE SWITCH Diagram

#

Description
Price

1

GRIP,THROTTLE This part replaces 57110-37200.

57110-37201

$29.68

2

CASE ASSY, THROTTLE

57100-37400

$106.20

3

SCREW This part replaces 02112-05208.

02112-05207

$1.97

4

LEVER, BRAKE | MODEL G/H This part replaces 57421-13000.

57421-13001

$11.86

4

LEVER,BRAKE | MODEL J This part replaces 57421-13010.

57421-13011

Unavailable

5

SCREW | MODEL G This part replaces 57431-13010.

09139-06114

$8.88

5

SCREW | MODEL H/J This part replaces 57431-13000.

57431-13001

$8.65

6

.NUT This part replaces 08319-21065.

08319-2106B

$2.31

7

BAND

09407-12402

$2.80

8

SCREW | OPT

57431-14A00

$8.97

9

COVER,KNUCKLE, | MODEL G, OPT This part replaces 57341-14A00-163.

57341-14A00-10V

Unavailable

9

GUARD, KNUCKLE RH (YELLOW) | MODEL H/J, OPT

57341-14A00-25Y

Unavailable

10

WASHER | OPT

09169-06033

$1.57

11

WASHER | OPT

09160-06019

$1.38

12

.NUT | OPT This part replaces 08319-21068.

08319-2106A

$1.89

13

WASHER,KNUCKLE COVER UPPER,L | OPT This part replaces 09169-10010.

09169-10024

$2.20
