Suzuki DL1000 (2009) 2ND AIR Diagram

#

Description
Price

1

.VALVE ASSY,2ND AIR REED

18450-06G00

$40.40

2

COVER,2ND AIR

18531-06G01

$13.20

3

BOLT

09103-06201

$2.54

4

HOSE, 2ND AIR VALVE FRONT

18461-06G00

Unavailable

5

HOSE, 2ND AIR VALVE REAR

18471-06G00

Unavailable

6

CLIP

09401-15101

$2.36

7

VALVE ASSY, AIR CUT

18510-35F00

Unavailable

8

CUSHION, 2ND AIR CLEANER

18517-06G10

Unavailable

9

HOSE, 2ND AIR CLEANER

18711-06G10

$14.78

10

HOSE, 2ND AIR VALVE VACUUM

13697-02A00

Unavailable

11

BRACKET, 2ND AIR VALVE

18610-06G00

$11.18

12

SCREW

03541-0612B

Unavailable
