Can-Am Commander LTD 1000, 2013 Drive System, Front Diagram

#

Description
Price

1

Hex. Flange Screw M8 X 20, Scotch Grip

207582044

$1.39

2

Hex. Flange Screw M10 X 125

230602546

$6.08

3

Hex. Flange Castellated Nut M18

232291413

$2.82

4

Hex. Flange Elastic Nut M10

233201436

$1.74

5a

Hex Flange Screw M12 X 16

250001039

$1.74

5b

HEX FLANGED SCREW M12 X 16, SCOTCH GRIP - Call your local BRP dealership

250000378

Unavailable

6

Hex. Flange Screw M6 X 25

250000787

$1.83

7

Not Available As Spare Parts

XXX

Unavailable

8

Chrome Wheel Nut M10 X 1.25 | XT

250100185

$2.48

9

Conical Spring Washer M18

250200171

$5.28

10

Flat Washer M12

250200102

$1.74

11

Cotter Pin

250400036

$1.74

14

O-Ring

293250246

$7.37

15

Ball Bearing

293350150

$51.93

16

Ball Bearing | 4X4

293350044

$30.39

17

Circlip

293370019

$4.98

18

Oetiker Gear Clamp 44.0MM | 4X4

293650138

$8.57

19

Tie Wrap 142 mm

293750002

$0.88

20

Oil Seal | 4X4

705401481

$18.43

21

Wear Ring | 4X4

705400036

$25.35

22

Circlip Joint | Not shown

705401349

$5.38

23

Oetiker Gear Clamp 36.1MM

509000045

$3.55

36

WHEEL CAP - Call your local BRP dealership

705400520

Unavailable

37

Front Tire

705402168

$235.35

37

Front Tire | XT Europe

705400961

$238.43

38

RIM_14 INCH X 7 - Call your local BRP dealership

705401380

Unavailable

39

DIFFERENTIAL KIT - Call your local BRP dealership

703500872

Unavailable

39a

Pinion Gear Shim 1.67 mm

705502061

$16.12

39b

Pinion Gear Shim .022"

705500075

Unavailable

39c

Shim | 4X4

705401604

$55.35

39d

Shim | 4X4

705401604

$55.35

40

Nut | 4X4

705401603

$36.89

41

Front Differential | XT, XT-P, Includes 9 to 29

703500908

$1,684.58

41a

FRONT COVER - Call your local BRP dealership

705400762

Unavailable

42

Wear Sleeve

705400780

$7.28

43

Not Available As Spare Parts

XXX

Unavailable

44

Wheel Stud

705401964

$10.14

48

Not Available As Spare Parts

XXX

Unavailable

49

Not Available As Spare Parts

XXX

Unavailable

52

Not Available As Spare Parts

XXX

Unavailable

54

COUPLING YOKE - Call your local BRP dealership

715900121

Unavailable

55

Ens. Croix*U-Joint Cross Kit

715900325

$69.20

57

Axle Drive Ass'y | Includes 1 to 7

705400915

$299.97

58

Grease Fitting

715900184

$4.62

59

Fixed Yoke Joint

715900116

$59.97

59a

Ens. Croix*U-Joint Cross Kit

715900325

$69.20

60

SPLINE YOKE - Call your local BRP dealership

715900120

Unavailable

60a

Not Available As Spare Part - Friction Washer

Unavailable

61

Not Available As Spare Parts

XXX

Unavailable

62

Not Available As Spare Parts

XXX

Unavailable

63

Rim Valve With Cap

705400193

$6.69

65

Boot Kit, Wheel Side

705401354

$41.51

65a

Oetiker Clamp, Large

715900260

$7.84

65b

Oetiker Clamp, Small

715900261

$4.39

66b

Oetiker Clamp, Large

715900262

$7.84

66

Boot Kit, Différential Side

705401355

$41.51

68

RH Front - Premium CV Axle | Includes 30 to 36

705401872

$232.74

68

LH Front - Premium CV Axle | Includes 39 to 45

705401871

$232.74

68a

JOINT_CV EXT - Call your local BRP dealership

705401353

Unavailable

68b

LH Plunging CV Joint

715900396

$249.20

68b

RH Plunging CV Joint

715900395

$249.20

77

FRONT COVER - Call your local BRP dealership

705401136

Unavailable

78

LH Front Knuckle

705401548

$129.20

78

RH Front Knuckle

705401549

$106.12

80

Not Available As Spare Parts

XXX

Unavailable

80

Not Available As Spare Parts

XXX

Unavailable

81

Wheel Hub

705401314

$129.20

82

Gasket | 4X4

705401618

$17.66

83

Ball Bearing | 4X4

705401606

$49.20

84

Ball Bearing | 4X4

705500260

$30.39

85

Needle Bearing | 4X4

705500261

Unavailable

86

Seal | 4X4

705500265

$16.12

87

O-Ring | 4X4

705500267

$6.25

88

Fill Level Plug | 4X4

705500504

$7.61

89

Copper Washer | 4X4

705500506

$0.36

90

Screw | 4X4

705401601

$9.29

91

VENT VALVE - Call your local BRP dealership | 4X4

705500893

Unavailable

92

Drain Plug | 4X4

705500894

$11.06

93

Pinion Gear Shim

705501162

$15.17

95

Rubber Boot

715900118

$13.83

96

1/2 Oz Weight

219704465

$4.35

97

1/2 Oz Weight

219704465

$4.35

98

1/2 Oz Weight

219704465

$4.35

99

Polyurethane Hose 10000Mm Long

219704410

$46.12

100

10 TEETH PINION - Call your local BRP dealership

705501588

Unavailable
