Yamaha BR250TA (BRAVO LT) 1997 STEERING GATE Diagram

#

Description
Price

1

GATE, STEERING

8BD-23871-00-00

Unavailable

2

BOLT, FLANGE

95817-06012-00

$1.40

3

BOLT, FLANGE(8AB)

95817-08020-00

$6.52

4

HOLDER, COUPLER

8F3-21794-00-00

Unavailable

5

SHIELD, HEAT

8AE-23892-00-00

Unavailable

6

SCREW, PAN HEAD(3TJ)

98507-06016-00

$2.27

7

WASHER(6TA)

92907-06600-00

$0.73

8

WASHER(6TA)

92907-06200-00

$5.76

9

CLAMP

90465-08028-00

$4.31

10

PIPE, SUCTION

8A5-14423-00-00

$11.45

11

SPRING TENSION 808144550000

90506-06083-00

$6.79
