Description

Price

1

FACE,FIXED DRIVE

21110-05H00

$90.96

2

FACE,MOVABLE DRIVE

21120-05H00

$102.76

3

COVER, MOVABLE

21122-05H00

$15.50

4

SEAL,MOVABLE DRIVE FACE OIL

21124-15F00

$9.90

5

SPACER,MOVABLE DRIVE

21125-05H00

$62.32

6

PLATE,MOVABLE DRIVE

21431-05H00

$59.37

7

DAMPER,MOVABLE DRIVE PLATE

21481-14F00

$6.61

8

ROLLER,MOVABLE DRIVEN

21650-15F40

$13.54

9

SCREW

02142-0410A

$1.22

10

FACE,FIXED DRIVEN

21210-05H00

$299.92

11

BEARING,FIXED DRIVEN RH This part replaces 21214-15F00.

21214-15F01

$24.45

12

FACE, MOVABLE DRIVEN

21240-05H00

$268.72

13

SPRING, MOVABLE DRIVEN

21243-15F30

$46.72

14

O-RING

21245-15F00

$4.73

15

SEAL, MOVABLE DRIVEN OIL

21247-31G00

$11.43

16

PIN,MOVABLE DRIVEN

21248-15F01

$4.48

17

SPACER,MOVABLE DRIVEN PIN

21249-15F00

$5.06

18

SHEET,MOVABLE DRIVEN

21471-15F20

$19.52

19

V BELT, DRIVE This part replaces 27601-05H00.

27601-05H10

$140.10

20

NUT

09140-18501

$2.80

21

WASHER

09164-18001

$2.97

22

BEARING This part replaces 08123-69047.

08123-6904B

$18.23

23

CIRCLIP This part replaces 08331-4137A.

08331-41379

$3.12

24

HOUSING,CLUTCH This part replaces 21220-05H02.

21220-05H30

$373.52

25

CLUTCH ASSY, SHOE | MODEL K7

21501-05H01

$310.07

25A

CLUTCH ASSY,SHOE | MODEL K8 This part replaces 21501-05H10.

21501-05H41

$313.15

26

NUT,SHOE CLUTCH

21518-15F00

$12.35

27

NUT, CLUTCH HOUSING

09140-16002

$2.90

28

WASHER, CLUTCH HOUSING

09164-16002
