Can-Am Defender MAX HD10, 2018 Cab Interior - Dashboard Diagram

#

Description
Price

1000>1000t

Heater System Kit

715004917

$1,625.99

1000a

Fan

520001536

$394.75

1000b

Duct Adaptor

520001672

$14.27

1000c

Rectangular Grid

520001673

$46.24

1000d

Potentiometer Switch Knob Ass'y | Includes 620 to 620c

705800585

$106.69

1000e

Potentiometer Switch Knob Ass'y | Includes 620 to 620c

705800585

$106.69

1000f

Grommet 5/8'' | Not Shown

520001676

$6.88

1000g

FUSE BOX - Call your local BRP dealership

520001679

Unavailable

1000h

Potentiometer Switch Knob Ass'y | Includes 620 to 620c

705800585

$106.69

1000j

Round Grid

520001681

$26.84

1000k

Duct Adaptor

520001682

$17.88

1000m

WIRING HARNESS - Call your local BRP dealership

520001683

Unavailable

1000n

Filter

520001537

$26.09

1000p

Console

520001546

Unavailable

1000q

Lower Cover

520001626

$39.52

1000r

Valve Ass'y 5/8''

520001685

$272.36

1000s

HVAC OVERLAY - Call your local BRP dealership

520001686

Unavailable

1000t

Torx Screw M6 X 20

250000722

$1.54

1010

Hex. Flange Elastic Nut M8

233281414

$1.31

1020

Torx Screw M6 X 20

250000722

$1.54

1100

Air Duct Kit

520001643

$182.06

1110

Tie Wrap 368 mm

293750008

$0.97

1120

Tie Rap Clip

293750062

$7.10

1130

Tie Wrap 368 mm

293750008

$0.97

1200

LH Support

520001619

$73.85

1210

RH Support

520001621

$54.45

1220

Central Support

520001623

$147.73

1230

Insert Half Hex Body M6 x 1.0

250100199

$2.91

1240

Hex. Flange Screw M6 X 30, Scotch Grip

207563044

$4.15

1505

Tuflok Plastic Rivet

293150230

$1.39

1730

Protector Decal

704906818

$12.63
