KTM 50 MINI ADVENTURE <1997> FRONT WHEEL Diagram

#

Description
Price

1

% FRONT WHEEL CPL. 1,50X10" SX

45009001000

Unavailable

2

AXLE FRONT CPL. L=202MM

45009081000

Unavailable

3

% TYRE 2,50X10" N.H.S. C 755

45009074000

Unavailable

4

TUBE 2,50X10'' TR6

45009075000

Unavailable

5

RIM BAND 10'' 22MM

45009073000

Unavailable

6

RIM 1,50X10'' STEEL

45009070000

Unavailable

7

SPOKE M3X90-110DG 10'' L/S

45009071000

Unavailable

8

SPOKE M3X92-88DG 10'' R/S

45009171000

Unavailable

9

SPOKE NIPPLE M3

45009072000

Unavailable

10

SPOKE M3X93-110DG 10'' L/S

45010071000

Unavailable

11

SPOKE M3X95-88DG 10'' R/S

45010171000

Unavailable

12

REAR WHEEL CPL. 1,50X10'' 50S

45010001000

Unavailable

13

AXLE REAR CPL. L=210MM

45010081000

Unavailable

14

% CHAIN 1/2x3/16" 94 ROLLS

31010065094

Unavailable

14

% CHAIN 1/2X3/16" 104 ROLLS

31010065104

Unavailable

15

MASTER LINK 1/2X3/16''

31010066000

Unavailable

19

HH COLLAR SCREW M 6X16 WS=8

0015060163

Unavailable

20

Pair of washers M6 NORDLOCK

50233041000

Unavailable

21

SPROCKET 44-T

45010051044

Unavailable

22

deep groove ball bearing 6001.

0625060016

Unavailable

25

BRAKE SHOES GARN.

45009035000

Unavailable

26

BRAKE SHOES GARN.

45010035000

Unavailable

27

SUPPORTING PLATE CPL. FRONT

45009030000

Unavailable

28

SUPPORTING PLATE CPL. REAR

45010030000

Unavailable

29

DISTANCE TUBE FRONT

45009011000

Unavailable

30

DISTANCE TUBE REAR

45010011000

Unavailable

31

WHEEL COVER CPL. 50 SXR

45010092000

Unavailable

32

CABLE TIE 300/4,8MM BLACK

44011076305

Unavailable
