KTM 450 XC-W 2009 ENGINE CASE Diagram

#

Description
Price

2

MAIN JET 125

57031523125

Unavailable

3

oil jet 70 M5

60030063070

Unavailable

4

VACUUM CONNECTION M6X1 ALU AH

58336020290

Unavailable

5

CASE BUSH

75030010000

Unavailable

6

DOWEL 21X12 03

54830027000

Unavailable

7

dowel sleeve 6x8x11.5

59030023000

Unavailable

8

DOWEL 17 X 13 X 12

51030026100

Unavailable

1

ENGINE CASE CPL.W. BEARING 09

78030000144

Unavailable

9

oil plug cpl. M24x3

58030020100

Unavailable

10

O-RING 19,00X3,00 NBR

0770191015

Unavailable

12

CU-seal ring DIN7603-12X18X1.5

58038022000

Unavailable

13

OILDRAIN PLUG W.MAG. M 12X1,5

58030021000

Unavailable

14

pipe plug DIN 906 M10x1

0906100100

Unavailable

20

T-PIECE 10/10/8MMM

78030071000

Unavailable

21

ENGINE BREATH HOSE EXC 08

78030087010

Unavailable

22

CARBURETOR BREATH HOSE EXC 08

78030087000

Unavailable

23

ENGINE CASE BREATH HOSE EXC 08

78030087020

Unavailable

50

HH COLLAR SCREW M6X75 TX30

0025060756

Unavailable

51

HH collar screw M6x60 TX30

0025060606

Unavailable

99

GASKET SET 450/530 EXC 08

78030099000

Unavailable
