Description

Price

10

Carbon Black, LH Upper Suspension Arm Ass'y With Balljoint This part replaces 706205156.

715011472

$276.89

20

Carbon Black, RH Upper Suspension Arm Ass'y With Balljoint This part replaces 706205157.

715011465

$276.89

21

Suspension Arm Bushing

706204409

$8.29

22

Interior Bushing

706202257

$9.22

23

Wear Plate

706202300

$2.31

24

Grease Fitting 90°

293550056

$1.37

30

Carbon Black, LH Lower Suspension Arm Ass'y With Balljoint This part replaces 706205243.

715010640

$276.89

40

Carbon Black, RH Lower Suspension Arm Ass'y With Balljoint This part replaces 706205244.

715010649

$276.89

50

Flange Screw M12 X 85

250000859

$3.95

55

Flange Screw M12 X 145

250000861

$5.47

60

Elastic Flange Nut M12

250001195

$2.15

70

Ball Joint

706203084

$35.35

80

Ball Joint

706202045

$35.35

210

LH Front Knuckle

706204785

$198.43

220

RH Front Knuckle

706204786

$147.66

225

Wear Plate

706202502

$2.75

230

Circlip

293370035

$2.55

240

Hex Nut M12

250100239

$1.64

241

Hardened Washer

706200281

$2.34

250

Cotter Pin

211400017

$0.25

270

Hex. Flange Elastic Nut M10

233201436

$1.74

280

Stabilizer Bar Ass'y

706203953

$96.89

290

LH Stabilizer Bar Link

706203611

$67.66

300

RH Stabilizer Bar Link

706203612

$67.66

320

Stabilizer Bar Bushing

706204564

$3.61

325

Grease Fitting 90°

293550056

$1.37

330

Clamp

706202460

$6.45

335

Support Plate

706202551

$4.60

340

Hex. Flange Screw M12 X 95

250000876

$5.54

345

Elastic Flange Nut M12

250001195

$2.15

350

Elastic Flange Nut M12

250001195

$2.15

540

Black, Link

706202708

$55.35

Can-Am Maverick MAX Turbo RR - RS - International, 2023 Suspension - Front Components Diagram
