Description

Price

10

Protective Plate Kit

715002374

$64.58

20

Hex. Flange Screw M6 X 20

207662054

$0.83

25

Carriage Bolt M6 X 20 | DS 650 X

207762044

$1.26

30

Flange Elastic Nut M6

233261434

$3.61

70

LH Structural Footboard

705011540

$115.35

80

RH Structural Footboard

705011542

$98.43

90

Carriage Bolt M6 X 35

207763554

$1.70

100

Flat Washer 6 mm

234062410

$0.64

110

LH Footrest Max

705003525

$124.58

120

RH Footrest Max

705003521

$124.58

130

Hex. Flange Screw M6 X 16

207661654

$1.74

135

Flat Washer

224061201

$1.11

140

Panel Nut M6 X 1.0

250100198

$1.73

320

Black, Rear Luggage Rack

715005986

$226.12

330

Torx Truss Screw M8 X 50

250000761

$6.18

330

Torx Truss Screw M8 X 50

250000761

$6.18

340

Elastic Flange Nut M8

233281464

$0.83

340

Elastic Flange Nut M8

233281464

$0.83

350

Hex Flange Screw M8 X 25 S.Grip

250001016

$1.07

475

Rubber Pad

293830163

$8.05

480a

Storage Cover | Model-Europe International

715004412

$207.66

480b

Storage Cover | Model-Europe International

715004412

$207.66

480c

LH Box Rear Latch

705007448

$10.98

480d

RH Box Rear Latch

705007921

$10.77

480e

Was 715900411 Neoprene Seal | Outlander MAX

219704452

$36.89

480f

Retaining Rod

705007531

$73.82

480g

Panel Nut M6 X 1.0

250100198

$1.73

480h

CAP - Call your local BRP dealership

414859400

$2.78

485

Heat Deflector Sheet

705007487

$4.62

487

Panel Nut M6 X 1.0

250100198

$1.73

525

Rear Facia | Except Model- Europe

705005576

$42.28

530

Red Reflector

705011221

$12.32

535

Stopper Rubber

705014429

$6.09

575a

Hex Flange Screw M6 X 25

250000841

$6.15

575b

Stainless Steel Flat Washer

234062670

$1.74

575c

Tuflok Plastic Rivet

293150230

$1.21

580

Torx Truss Screw M6 X 25

250000807

$1.74

590

Torx Screw M6 X 20

250000722

$1.34

770

Tuflok Plastic Rivet

293150230

$1.21

830

Rear Bumper kit | Package Hunter

715001911

$138.43

840

Cap

705202455

$4.62

930

LH Extension Panel

715001897

$27.66

940

RH Extension Panel

705004348

$27.66

960

Heat Shield

705006870

$5.52

970

Heat Shield

705006871

$5.52

1010

Seat Holder

705007948

$55.35

Can-Am Outlander MAX 570 EFI - 2020 Body - Rear Section - XT Diagram
